solaris… wtf?!?

Just found …

I never realized that there is a really easy way to “monitor” your Solaris in a way to use build-in SMF and FMA monitors and send a mail in case of diagnoses.

# svccfg setnotify problem-diagnosed mailto:pressy@solaris.wtf
# svcadm enable http:apache24
# mv /etc/apache2/2.4/httpd.conf /etc/apache2/2.4/httpd.conf_bu
# pkill httpd
# svcs -xv
svc:/network/http:apache24 (Apache 2.4 HTTP server)
State: maintenance since Fri May 24 11:51:19 2019
Reason: Method failed.
See: http://support.oracle.com/msg/SMF-8000-8Q
See: http://httpd.apache.org
See: man -M /usr/apache2/2.4/man -s 8 httpd
See: /var/svc/log/network-http:apache24.log
Impact: This service is not running.

uhhh… got mail:

SUNW-MSG-ID: SMF-8000-YX, TYPE: Defect, VER: 1, SEVERITY: Major
EVENT-TIME: Fri May 24 11:51:19 CEST 2019
PLATFORM: ORCL,SPARC-T4-1, CSN: AKBLABLA42, HOSTNAME: sparc-server
SOURCE: software-diagnosis, REV: 0.2
EVENT-ID: e0114186-cd70-4085-84aa-802b091a399e
DESC: Service svc:/network/http:apache24 failed - a start, stop or refresh method failed.
AUTO-RESPONSE: The service has been placed into the maintenance state.
IMPACT: svc:/network/http:apache24 is unavailable.
REC-ACTION: Run 'svcs -xv svc:/network/http:apache24' to determine the generic reason why the service failed, the location of any logfiles, and a list of other services impacted. Please refer to the associated reference document at http://support.oracle.com/msg/SMF-8000-YX for the latest service procedures and policies regarding this diagnosis.

Nice… you could set several tags like problem-diagnosed, problem-updated, problem-repaired, problem-resolved, to- or from- (maintenance, from-online, to-degraded) or all for every transition.

And it would also work for specific services:

# svccfg -s application/myservice setnotify problem-diagnosed mailto:pressy@solaris.wtf

Easy, isn’t it?

Last time installing an Oracle DB on Solaris 11.4 SPARC I realized missing extra large memory page sizes. I want to see 16GB huge pages on SPARC but only got 2GB pages as largest allocated memory by Oracle. Well, still bigger than on x86, where you will get 4k/2M/1G but dynamic large pages chosen by the database like needed is a very nice feature on SPARC:

Multiple Page Size Support

MPSS feature in Oracle Solaris allows an application to use different page sizes for different regions of virtual memory. Larger page sizes let the Translation Lookaside Buffer (TLB) map more physical memory using the fixed number of TLB entries. Larger pages may therefore reduce the cost of virtual-to-physical memory mapping and increase overall system performance.

First of all we need a domain which provides 16GB pages which is controlled by the SPARC hypervisor (aka LDOM). This is documented by the LDOM parameter “effective-max-pagesize” and “hardware-max-pagesize”.

To get a given effective-max-pagesize of 16GB the LDOM must be assigned in a layout that includes at least one MBLOCK that has 4 aligned physical and contiguous ranges of 16GB. That means at least one MBLOCK with 4x16GB (64GB) and this MBLOCK *must* be aligned to a 16GB hardware address.

Alignment can be a tricky part since “LDOMs” reserve a small amout of memory for internal use which means the first available block might not be aligned to our needed 16GB hardware address. For example you could use hardware addresses for that like:

root@t7primary01:~# ldm set-mem mblock=0x400000000:64g my64Gdomain
root@t7primary01:~# ldm list-constraints my64domain | grep page
    effective-max-pagesize=16GB
    hardware-max-pagesize=16GB
root@t7primary01:~#

Pfua… ok… now it should work but still… no 16GB pages…

After struggling around with support I got an answer from a kernel developer… extra large pages are disabled on “small” systems with less than 512GB of memory (in pages). There were some issues (internal Bug) but with latest and greatest versions systems actually run satisfactorily.

Anyhow it is still disabled by this threshold (might chance again), but yes, it also might not really be necessary on smaller systems. If you still want to use extra large pages, you can adjust the threshold:

root@t7primary01:~# ldm list-constraints primary | grep -i 0x2
0x2000000000 256G
root@t7primary01:~# root@t7primary01:~# grep xlarge /etc/system
set xlarge_mem_threshold = 0x1900000
root@t7primary01:~# pagesize -a
8192
65536
4194304
268435456
2147483648
17179869184
root@t7primary01:~# pmap -sx $(ps -ef -o pid,comm | awk '/smon/ {print $1}') | grep osm

0000000380000000      8192      8192    -      8192   4M rwxsR--  [ osm shmid=0x0 ]
0000000380800000      4096      4096    -      4096    - rwxsR--  [ osm shmid=0x0 ]
00000003C0000000    262144    262144    -    262144 256M rwxsRi-  [ osm shmid=0x4 ]
0000000400000000 117440512 117440512    - 117440512  16G rwxsRi-  [ osm shmid=0x1 ]
0000002000000000   6291456   6291456    -   6291456   2G rwxsRi-  [ osm shmid=0x2 ]
0000002180000000   1835008   1835008    -   1835008 256M rwxsRi-  [ osm shmid=0x3 ]
root@t7primary01:~#

Have fun showing your DBAs a possible platform performance feature…
